Half Coupler Small Busbar 48-51/30/100kg
SKU:
888813
EAN: 4042659143840
This coupler was specially developed for trade fair and retail constructions. It can be used to attach 3-phase power rails to trusses.
Non-binding price recommendation
€8.90
Interested in this product?
Register now
General
| Approved by: | DIN EN 13814:2004 |
|---|---|
| Colour: | Aluminum |
| Compatibility: | 48-51 mm |
| Material: | Aluminum 6061 T6 |
| TÜV certificate: | No |
Fittings
| Clasp: | M8 wing nut |
|---|---|
| Retaining screw: | für 3-Phasen Stromschiene |
Technical Data
| Tensile load: | 100,00 kg |
|---|---|
| Width: | 30 mm |
Shipping Data
| Length: | 80 mm |
|---|---|
| Width: | 80 mm |
| Height: | 30 mm |
| Weight: | 0.14 kg |
| PU: | 50 |
