F43 450cm
SKU:
F43450
EAN: 4042659114253
The F43 truss series by Global Truss is a TÜV approved 3-point system with an external dimension of 40cm. This system is used for single truss lines as well as complex constructions with greater loads. A maximum span of up to 18 meters can be created with this system.
The F43 truss is built with 50 x 2mm main tubes and 25 x 3mm diagonal braces of aluminium. The truss pieces are connected with the included conical connectors. This truss and all other Global Truss series can be powder coated in every RAL colour.
Non-binding price recommendation
€568.00
Interested in this product?
Register now
General
| Colour: | Aluminum |
|---|---|
| Material: | Al EN AW-6082 T6 |
| TÜV certificate: | Yes |
Technical Data
| Edge dimension: | 40 cm |
|---|---|
| Number of points: | 3-point |
| System: | F43 |
| Truss length: | 450 cm |
| Type: | straight |
Main pipe
| Diameter main pipe: | 50 mm |
|---|---|
| Wall thickness main pipe: | 2 mm |
Brace
| Diameter Brace: | 25 mm |
|---|---|
| Wall thickness Brace: | 3 mm |
Hardware
| Dimensions (L/W/H): | 4500 x 400 x 400 mm |
|---|---|
| Weight: | 23,60 kg |
Shipping Data
| Length: | 4500 mm |
|---|---|
| Width: | 400 mm |
| Height: | 400 mm |
| Weight: | 26.98 kg |
| PU: | 1 |
straight
corner
